Applications
It is used in control & supervision circuit of A.C 50-60HZ, rated voltage 750V or lower with demand on low smoke, halogen-free and flame-retardant performance,free from toxicity & corrosion.
Executive Standard    As the enterprise is standard with reference to GB9330-88 standard
Performance
(1) Class A or class B firing in bundle (carbonized part Height):<=2.5m
(2) No flame spreading in fire (part intact Distance): >=50mm
(3) Smoke Density (min.light penetration rate): >= 60%
 (4) HCL Content: <=0.5mg/g

Cable Length
1.the length of the cable in coil should be 100 metres, and that of cable on drum should be no less than 100 metres ;
2. it dependson both agreements with length error allowance no more than ±0.5%
